SmartBottle-Team-03
Ethimedix Team

The TEAM version of the SmartBottle is used for the treatment of post-operative, chronic or palliative pain and acts as a secure metering dispenser for liquid drinkable medicament.
Intended fo use by healthcare professionals, this device can be placed on a trolley during patient rounds. With a simple pressure on the central button, it is possible to adjust the volume of drug to be delivered for each patient (5 to 15 mL).

Ethimedix Team
SmartBottle Team
The TEAM version of the SmartBottle is used for the treatment of post-operative, chronic or palliative pain and acts as a secure metering dispenser for liquid drinkable medicament.
Intended fo use by healthcare professionals, this device can be placed on a trolley during patient rounds. With a simple pressure on the central button, it is possible to adjust the volume of drug to be delivered for each patient (5 to 15 mL).

SAFETY

  • Biometric authentication of the medical staff

  • Neutralization system in case of tampering

  • Adherence to treatment

  • No risk of misuse and diversion

  • No lockout period between doses

COMFORT

  • Nurse time savings

  • Easy modification of doses prescribed for one patient or another

  • Maintenance free and up to 2 years of autonomy

  • Can be placed on a trolley for ease

  • Easy to carry thanks to its compact design

  • Non-invasive

  • No false alarms

TREATMENT

  • Distributor and secured dosing

  • Simple and secured programmingtion

  • Dispensing range per dose: between 5ml to 15ml

  • Short-term and long-term care

  • Traceability and dose-distribution tracking

  • Up to 20 different authorized caregivers can deliver doses

AdministrationAdjustable doses from one patient to another
Dispensing range5 to 15mL per dose
Maximum dispensed quantity1000 mL
Drug bagPVC conform to USP standard
Display4 LED
Operating conditionsAmbient temperature: from 15 to 30°C
Relative humidity: max 93%
Storage conditions between two usesAmbient temperature: from 15 to 30°C
Power supplyDC 3.6V (Non rechargeable Battery)
Mean lifetime of the battery = 2 years (i.e. approx. distribution of 4’000 doses)
ClassificationClass I, EC Declaration of Conformity
Type BF
IP31: protected against intrusion of solid foreign objects (≥ 2.5mm diameter)
and against ingress of water with harmful effects (vertically falling water drops)
Dimensions29cm (H) x 14cm (diameter)
Weight1kg (empty)
Product referenceSBP1000
